Johnson & Allen JAYMI Electromagnetic Yoke
230V AC electromagnetic yoke, small, compact and lightweight, weighing 2.3kg and lifting 4.5kg or more. Steel guard plates protect the pole feet, with a self-resetting thermal cut-out, supplied with a lift-test certificate and canvas carry bag.
Specifications
| Specification | Value |
|---|---|
| Power | 230V AC, 1.3A, 50/60Hz |
| Weight | 2.3kg |
| Dimensions (L×W×H) | 260 × 50 × 190mm |
| Lifting Strength | >4.5kg (44N) |
| Magnetic Field | >2.5kA/m @ 152mm spacing |
| Pole Spacing | 60–210mm (135mm recommended) |
| Pole Contact Size | 20 × 20mm |
| Duty Cycle | 25% max (30 sec ON) |
| Ingress Protection | IP56 |
