High Temperature UT Probe
Dual element ultrasonic probes rated for high-temperature thickness gauging. The GT560 covers a wider measuring range at higher temperatures; the GT-12 is suited to shorter-range, moderate high-temperature work.
Select model
Available configurations
| Model | Frequency | Element Size | Measuring Range (Steel) | Temperature Range | Connector |
|---|---|---|---|---|---|
| GT560 | 5MHz | 10mm | 1–508mm | -55°C to +550°C | Microdot |
| GT-12 | 3MHz | 10mm | 4.0–80mm | Up to 480°C | LEMO 00 |
